Brand:
Huawei
|
|
Inverter Type:
Grid
|
|
Phases:
Three-phase
|
|
Rated AC Power (kW):
150
|
|
Protection Rating (IP):
IP65
|
|
MPPT:
7
|
|
Strings por MPPT:
3
|
|
European Efficiency (%):
98,4
|
|
Max. Input Voltage (V):
1.100
|
|
Rated Output Voltage:
380 V AC / 400 V AC / 480 V AC
|
|
Operating Temperature:
-25 °C … +60 °C
|
|
Maximum Efficiency (%):
98,6 (400 V) / 98,8 (480 V)
|
|
Backup Function:
No
|
|
Length (mm):
1000.0
|
|
Depth (mm):
395.0
|
|
Width (mm):
710.0
|
|
Weight (kg):
115
|
|
Warranty (years):
10
|
|
Model:
SUN2000-150K-MG0
|
|
Max. Current per MPPT:
48 A por MPPT / 23 A por entrada
|
|
Max. Short-Circuit Current:
66 A
|
